20Amp MPPT Solar Charge Controller 12/24V Battery Regulator Auto USB

MPPT Solar Charge Controller adopts DC/DC converting technology and MCU technology.adjust the working point of the solar array intelligently to make the solar array realize the maximum power output.When the external condition changes, MPPT controller bases on the MCU theory to track the maximum working point of solar panels, this can improve the using efficiency of the solar panels and decrease the solar generating costs. Compared with PWM solar charge controllers,MPPT improve the output efficiency of solar panel by 5% to 30%(the output increasing proportion affected by the factors such as the attribute of solar panels, environmental temperature and lighting conditions)



Features:

Advanced MPPT maximum power point tracking technology, the tracking efficiency is no less than 99.5%.

High quality components are used to improve the system performance, and the maximum conversion efficiency can reach97%.

Super fast maximum power tracking speed while ensuring tracking efficiency.

Accurate identification and tracking of the maximum power point of multi-wave peak.

Reliable maximum input power of pv array to ensure the safety of equipment.

Wide pv array maximum power point operating voltage range.

12/24v automatic voltage identification

The LCD is designed to dynamically display the operation data and working status of the equipment.

Various load control modes: general mode, light control mode, dual time mode, pure charger mode and timing mode.

Seal, GEL, Flooded, LifePO4 and Li(NiCoMn)O2 charging process can be selected.

The function of battery temperature compensation.

Power statistics recording function.

External display unit and other peripherals, realize real-time data view and parameter setting function.
